Energy & Climate Control Door Systems AirShield™ Model AL3014
The McKEON AirShield™ Model AL3014 is tested, listed and labeled to ANSI/DASMA 105, DASMA 112 and ASTM E283 for air infiltration and exfiltration.
The 2024 International Energy Conservation Code (IECC), and previous editions, require rolling door assemblies to be tested and labeled for a maximum air leakage of 1.00 cfm/ft2 when tested in accordance with ANSI/DASMA 105 or ASTM E283 at 1.57 psf. Air leakage is defined by the IECC as:
AIR LEAKAGE. The uncontrolled airflow through the building thermal envelope caused by pressure differences across the building thermal envelope. Air leakage can be inward (infiltration) or outward (exfiltration) through the building thermal envelope.
The McKEON ClimateShield™ Model AL3014 is a revolutionary product designed to improve energy efficiency by complying with the IECC and other similar energy codes and standards. When insulated, the assembly also provides superior thermal and sound transmission performance making it the perfect choice for climate control and overall ambiance of the space.
Ratings
Listed & labeled – less than 1.00 cfm/ft2 for infiltration and exfiltration
Optional:
Thermal protection with an R Value up to 8.0
Code Compliance
2024 IECC: International Energy Conservation Code
Size
Widths to 24′ and heights to 48′; for larger sizes and custom configurations consult the factory
Finishes
Clear Anodized
Powder coat of any color as selected
